Ariel 4G Square Four 1000 1940
The Ariel 4G Square Four 1000 1940 by ariel, model (1940), demonstrates how modern engineering meets rider needs. As a Allround, it is powered by a Carburettor. SU MC2 carburettor engine designed for efficiency and durability. Specifications are critical for understanding what makes this motorcycle unique, from its body design to its riding comfort. By analyzing these details, buyers can confidently assess whether the Ariel 4G Square Four 1000 1940 aligns with their lifestyle and road conditions.
General Information
| body type | Allround |
| bike category | --- |
| seating capacity | --- |
| length | 2083 mm (82.0 inches) |
| width | --- |
| height | --- |
| wheelbase | 1422 mm (56.0 inches) |
| ground clearance | --- |
| dry weight | 193.0 kg (425.5 pounds) |
| fuel tank capacity | 23.00 litres (6.08 US gallons) |
| battery capacity | --- |
| curb weight | --- |
| seat height | --- |
| charging time | --- |
| battery type | --- |
| starting system | Kick |
Engine Specifications
| powertrain architecture | Square four cylinder |
| fuel type | Carburettor. SU MC2 carburettor |
| Engine Type | --- |
| engine displacement | 997.0 ccm (60.84 cubic inches) |
| power | 35.0 HP (25.5 kW)) @ 5500 RPM |
| torque | --- |
| bore x stroke | 65.0 x 78.0 mm (2.6 x 3.1 inches) |
| engine size | --- |
| compression | 6.0:1 |
| fuel system | Carburettor. SU MC2 carburettor |
| engine cooling | Air |
| engine oil capacity | --- |
| Battery Voltage (Electric) | --- |
| Motor Power (Electric) | --- |
| Electric Start | --- |
| gearbox | 4-speed |
Performance
| top speed | --- |
| acceleration 0 - 100 km/h | --- |
| weight to power ratio | 0.1813 HP/kg |
| weight to torque ratio | --- |
Fuel Economy and Emissions (ICE)
| fuel consumption | --- |
| co | --- |
| emission standard | --- |
Drivetrain and Transmission
| drivetrain architecture | --- |
| drive wheel | --- |
| transmission type | Chain (final drive) |
| clutch type | --- |
Suspension and Brakes
| front suspension | Telescopic fork |
| rear suspension | Plunger-link spring |
| Front brakes | --- |
| front brakes | Expanding brake (drum brake) |
| rear brakes | Expanding brake (drum brake) |
| abs | --- |
| traction control | --- |
Steering and Tires
| steering type | --- |
| driveline | --- |
| front tire size | 3.25-19 |
| rear tire size | 4.00-18 |
| wheel type | Wire spoked |
| wheel size | --- |
Additional Features
| frame type | Tubular single loop |
| Instrument Cluster | --- |
| Features | --- |
| headlight | --- |
| Storage | --- |
Frequently Asked Questions
What type of riders is the ariel 1940 best suited for?
The ariel 1940 caters to riders who prefer reliable performance, stylish design, and practical fuel efficiency, whether for daily commutes or weekend rides.
Does the ariel 1940 require high maintenance?
No, the ariel 1940 is designed for easy maintenance with durable components and a service-friendly structure. Regular servicing ensures long-lasting performance.
What makes the ariel 1940 unique compared to other bikes in its class?
The ariel 1940 stands out due to its Allround design, reliable Carburettor. SU MC2 carburettor engine, and advanced features that provide both comfort and performance.
